Code: JXS10 (1210)
Explore Jauch Quartz's JXS10 series crystals: 24.0-80.0 MHz, precise frequency, low capacitance. Ideal for stable, low-power electronics.
Price on Application
JXS10 (1210) | SMD Seam Seal | Quartz Crystal 24.0-80.0 MHz
Features:
- 4 Pad Version 1.2x1.0mm
- ± 10 ppm type available
- High frequency stability and low ESR
- Metal lid allows EMI shielding
- Reflow soldering temperature: 260°C max
Specifications:
• TYPE JXS10
• Frequency range 24.0 ~ 80.0 MHz (fund. AT-cut)
• Frequency tolerance at 25 °C ± 10 ppm / ± 20 ppm / ± 30 ppm
• Load capacitance CL 8 pF standard (option: 6 pF / 7 pF / 9 pF / 10 pF)
• Shunt capacitance CO < 2 pF
• Storage temperature -40 °C ~ +90 °C
• Drive level max. 100 μW (10 μW recommended)
• Aging < ± 3 ppm first year (option: < ± 2 ppm first year for tol. ± 10 ppm)
• Frequency range 24.0 ~ 80.0 MHz (fund. AT-cut)
• Frequency tolerance at 25 °C ± 10 ppm / ± 20 ppm / ± 30 ppm
• Load capacitance CL 8 pF standard (option: 6 pF / 7 pF / 9 pF / 10 pF)
• Shunt capacitance CO < 2 pF
• Storage temperature -40 °C ~ +90 °C
• Drive level max. 100 μW (10 μW recommended)
• Aging < ± 3 ppm first year (option: < ± 2 ppm first year for tol. ± 10 ppm)
