Discover our JXS22 series quartz crystals, specially designed for wireless applications with 14 standard frequencies as per the ESR list. For a broader range of frequencies, please see the general JXS22 datasheet. These crystals are engineered for precision with a frequency tolerance of ±10 ppm at 25°C and offer versatile load capacitance options of 8, 9, 10, and 12 pF to suit a variety of design specifications. With a shunt capacitance of less than 3 pF, they are optimized for efficient operation over a wide temperature range of -40°C to +105°C. Featuring a maximum drive level of 100 μW, with 10 μW recommended for enhanced longevity, they boast an exceptional aging rate of less than ±1 ppm in the first year, ensuring reliable performance for critical wireless applications
Jauch | JXS22-WA | SMD Seam Seal for wireless 2.5x2.0x0.55mm
Features
- For wireless applications, 2.5 x 2.0 mm
- Perfect reference crystal for wireless applications
- For IoT using BlueTooth, ZigBee, NFC and more
- High frequency stability and low ESR
- Metal lid allows EMI shielding
- Special frequencies for Wireless applications
- 14 standard frequencies shown in ESR list (For other frequencies refer to general JXS22 datasheet)
- Frequency tolerance at 25 °C ± 10 ppm*
- Load capacitance CL 8 pF / 9 pF / 10 pF / 12 pF*
- Shunt capacitance CO < 3 pF
- Storage temperature -40 °C ~ +105 °C
- Drive level max. 100 μW (10 μW recommended)
- Aging < ± 1 ppm first year
